Fujifilm Fujinon MK-X 18-55mm T2.9 for Fuji X-Mount

PRODUCT HIGHLIGHTS

• Covers Super 35 Format
• Fuji X-Mount with Electrical Contacts
• Consistent T2.9 Aperture Over Zoom Range
• 3 x Standard 0.8 MOD Gears
• Clickless 9-Blade Iris
• 200° Focus Rotation and Macro Mode
• Color Matched to Fujinon HK/ZK/XK Series
• 85mm Front Outside Diameter
• Weighs 2.16 Pounds
• Flange Focal Distance Adjustment
•


• The Fujinon MKX18-55mm T2.9 Lens in X-Mount is a lightweight cine-style zoom lens for X-mount cameras with a Super 35mm-sized sensor. The electrical contacts within the lens mounts allows communication with X-series cameras. It features a mechanical design with three independent lens control rings: focus, iris, and zoom. Each ring incorporates a cine-style gear with a 0.8 MOD for interfacing with standard cine -style lens accessories. The focus ring features approximately 200° of rotation, which provides room for precise focus pulls, and the iris is clickless, enabling smooth iris pulls. The lens also incorporates a macro mode for close focusing capabilities.

  The lens is color matched to other Fujinon lenses such as the HK, ZK, and XK series, which enables smooth intercutting between lenses. The 85mm front enables use with many cine-style matte boxes via use of optional step-up rings (rings not included). The lens weighs only 2.16 pounds, which is fairly light for a cinema zoom that holds focus and aperture throughout the focal length range. It is designed for cameras with a Fuji X-mount, so it has a short flange focal distance, but the lens allows for flange focal distance adjustment so you can fine-tune it to the camera you are using the lens on.

  The electical contacts within the lens mount enables communication with X-series cameras, which allows for correction of distortion and color/brightness shading to prevent vignetting. This communication also enables you to achieve a variety of color expressions when using Film Simulation modes.

  T2.9 to T22 aperture with 9 iris blades for attractive bokeh

  The 28.5mm diameter image circle covers the 3-perf super 35 format with a 16:9 aspect ratio

  Industry standard 0.8 film pitch gears for focus, zoom, and iris control

  The gear rings positions for focus, zoom, and iris are located at the same position on both lenses in the MKX series, making switching between the two zooms quick as you don't have to adjust the position of lens accessories

  Both lenses in the MKX series have the same weight and length so here is no need to rebalance your camera when you change from one lens to the other

  200° focus barrel rotation

  No shims are required to adjust the flange focal distance as this lens has a built-in adjustment mechanism

  Macro focus function available




  Specifications :

  Focal Length	18 - 55mm
  Lens Mount	Fujifilm X
  Format	Super 35/APS-C
  Image Circle	28.5 mm
  Maximum T-Stop	T2.9 - 22
  Minimum T-Stop	Not Specified by Manufacturer
  Minimum Focus Distance from Image Plane	2.8' / 0.85 m
  Elements/Groups	22 / 17
  Iris Blades	9
  Gear MOD & Pitch	Focus: 0.8 MOD / 32 Pitch Iris: 0.8 MOD / 32 Pitch Zoom: 0.8 MOD / 32 Pitch
  Front Diameter	85 mm
  Filter Thread	82 mm
  Focus Scales	Not Specified by Manufacturer
  Focus Rotation	200°
  Iris Rotation	Not Specified by Manufacturer
  Zoom Rotation	Not Specified by Manufacturer
  Tilt Rotation	Not Specified by Manufacturer
  Zoom Ratio	3x
  Electronic Communication	Yes
  Tripod Mounting Thread	1/4"-20
  Dimensions (W x H)	Not Specified by Manufacturer
  Length	8.12" / 20.62 cm
  Weight	2.16 lb / 0.98 kg
